Lectura specs Construction machinery Tracked Asphalt Pavers Tracked Asphalt Pavers Vögele Vögele Super 1800-3i SprayJet specifications

Vögele Super 1800-3i SprayJet Specifications & Technical Data (2021-2023)

Rate this machine now!

Weight: 22.81t – Transport length: 6.04m – Transport width: 3m – Transport height: 2.825m – Standard width: 3.265m – Max. width: 9m

Technical specs - Super 1800-3i SprayJet Vögele

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 22.81 t
  • Transport length 6.04 m
  • Transport width 3 m
  • Transport height 2.825 m
  • Standard width 3.265 m
  • Max. width 9 m
  • Drive DM
  • Operating speed 24 m/min
  • Type of screed V/T
  • Model series Universal Class
  • Engine manuf. Cummins
  • Engine type B6.7–C173
  • Engine power 129 kW
  • Displacement 6.7 l
  • No. of cylinders 6
  • Emission level EU Stage V, US EPA Tier 4f

More technical details, like: average fuel consumption, fuel consumption range (min - max), hydr. extension from, hydr. extension up to, soil pressure, bunker capacity, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention

Special equipment

  • Diesel particulate filter
  • Bilateral levelling automatic
  • Vibration
  • High compaction
  • Spray unit
  • Tamper
