Bomag BF 800 C 3 S 500
- Weight:
- 23 t
- Transport length:
- 6.8 m
- Transport width:
- 2.55 m
- Transport height:
- 3.02 m
Bomag BF 800 C 3 S 500 Specifications & Technical Data (2020-2025)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Technical specs - BF 800 C 3 S 500 Bomag
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 23 t
- Transport length
- 6.8 m
- Transport width
- 2.55 m
- Transport height
- 3.02 m
- Standard width
- 2.55 m
- Max. width
- 9 m
- Hydr. extension from
- 2.55 m
- Hydr. extension up to
- 5 m
- Drive
- DH
- Bunker capacity
- 7.2 m³
- Operating speed
- 25 m/min
- Type of screed
- V/T
- Model series
- BF
- Engine manuf.
- Deutz
- Engine type
- TCD2012 L06
- Engine power
- 135 kW
- Revolutions at max torque
- 2000 rpm
- No. of cylinders
- 6
- Emission level
- T3
More technical details, like: soil pressure, dimension lxwxh, displacement, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention
Special equipment
- Diesel particulate filter
-
No
- Bilateral levelling automatic
-
No
- Vibration
-
Yes
- High compaction
-
Yes
- Spray unit
-
No
- Tamper
-
Yes
