Lectura specs Construction machinery Tracked Asphalt Pavers Tracked Asphalt Pavers Astec Astec CARLSON CP75 II specifications

Astec CARLSON CP75 II Specifications & Technical Data (2022-2023)

Rate this machine now!

Weight: 6.35t – Transport length: 3.785m – Transport width: 3.073m – Transport height: 1.892m – Standard width: 2.43m – Max. width: 4.59m

Technical specs - CARLSON CP75 II Astec


Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 6.35 t
  • Transport length 3.785 m
  • Transport width 3.073 m
  • Transport height 1.892 m
  • Standard width 2.43 m
  • Max. width 4.59 m
  • Operating speed 47.2 m/min
  • Engine manuf. Deutz
  • Engine type 2.9 L4
  • Engine power 74 HP
  • Emission level Tier 4 Final/Stage IV

More technical details, like: average fuel consumption, fuel consumption range (min - max), hydr. extension from, hydr. extension up to, drive, soil pressure, bunker capacity, type of screed, model series, dimension lxwxh, displacement, revolutions at max torque...

Show more

Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention

Special equipment

  • Diesel particulate filter
  • Bilateral levelling automatic
  • Vibration
  • High compaction
  • Spray unit
  • Tamper
