    Bomag BW 218 D-40 Specifications & Technical Data (2009-2018)

    Rate this machine now!

    Weight: 17.2t – Transport length: 5.93m – Transport width: 2.48m – Transport height: 2.985m – Vibration: e – Drive: A

    Technical specs - BW 218 D-40 Bomag


    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 17.2 t
    • Transport length 5.93 m
    • Transport width 2.48 m
    • Transport height 2.985 m
    • Vibration e
    • Drive A
    • Travel speed 11 km/h
    • Frequency 30/36 Hz
    • Roller width 2.13 m
    • Rollers Ø 1.5 m
    • Amplitude 1.8/0.9 mm
    • Turning radius outside 3.494 m
    • Statical line load 62.9 kg/cm
    • Engine manuf. Deutz
    • Engine type BF4M1013EC
    • Engine power 114 kW

    More technical details, like: turning radius inside, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

    Basic model with ROPS cabin

    Special equipment

    • Diesel particulate filter
    • Sheep foot
    • Oscillation
    • Compression control
    • Aircondition
