    Lectura specs Construction machinery Crawler dumper Crawler dumper Yanmar Yanmar 80 HI specifications

    Yanmar 80 HI Specifications & Technical Data (2011-2015)

    Rate this machine now!

    Weight: 4.2t – Transport length: 1.9m – Transport width: 0.8m – Transport height: 1.14m – Net load: 0.8t – Dump capacity: 0.38m³

    Technical specs - 80 HI Yanmar


    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 4.2 t
    • Transport length 1.9 m
    • Transport width 0.8 m
    • Transport height 1.14 m
    • Net load 0.8 t
    • Dump capacity 0.38 m³
    • Travel speed 6,3 km/h
    • Track width 180 mm
    • Engine manuf. Yanmar
    • Engine type LN100AE
    • Engine power 7.5 kW

    More technical details, like: driver protection, soil pressure, loading height, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, engine manufacturer...

    Show more

    Basic model with ROPS cabin and std. trough

    Special equipment

    • Track adjustment
    • Bucket
    • Heated dump body
    • Electric starter
    • Trough liftable
    • Aircondition
