    Wirtgen W 50 Ri Specifications & Technical Data (2021-2023)

    Rate this machine now!

    Weight: 6.4t – Standard tyres: 530x300 / 559x254 – Cutting width: 500mm – Cutting depth: 210mm – Operating speed: 48m/min – Travel speed : 12km/h

    Technical specs - W 50 Ri Wirtgen


    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 6.4 t
    • Standard tyres 530x300 / 559x254
    • Cutting width 500 mm
    • Cutting depth 210 mm
    • Operating speed 48 m/min
    • Travel speed 12 km/h
    • Transport length 3.9 m
    • Transport width 1.64 m
    • Transport height 3.55 m
    • Engine manuf. Deutz
    • Engine type TCD4.1 L4
    • Engine power 105 kW
    • Displacement 4.1 l
    • Emission level Euro V / US Tier 4f

    More technical details, like: track width, turning radius outside, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

    Basic model with cutting tools

    Special equipment

    • Diesel particulate filter
    • Cabin
    • Front loading conveyor
    • Infrared heater
    • Aircondition
