    Cold Milling Machines Wirtgen W 150 CFi
    Cold Milling Machines Wirtgen W 150 CFi Cold Milling Machines Wirtgen W 150 CFi Cold Milling Machines Wirtgen W 150 CFi Cold Milling Machines Wirtgen W 150 CFi
    Wirtgen

    Wirtgen W 150 CFi Specifications & Technical Data (2021-2023)

    Rate this machine now!

    Weight: 19.3t – Track width: 260mm – Cutting width: 1500mm – Cutting depth: 330mm – Operating speed: 40m/min – Travel speed : 7.5km/h

    Technical specs - W 150 CFi Wirtgen

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 19.3 t
    • Track width 260 mm
    • Cutting width 1500 mm
    • Cutting depth 330 mm
    • Operating speed 40 m/min
    • Travel speed 7.5 km/h
    • Transport length 6.975 m
    • Transport width 2.37 m
    • Transport height 3.77 m
    • Engine manuf. Cummins
    • Engine type QSL9
    • Engine power 298 kW
    • Displacement 8.9 l
    • Emission level Euro V

    More technical details, like: standard tyres, turning radius outside, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

    Basic model with cutting tools

    Special equipment

    • Diesel particulate filter
    • Cabin
    • Front loading conveyor
    • Infrared heater
    • Aircondition

    Carbon footprint calculator for Cold Milling Machines

    See the ERA equipment CO2 Calculator to track the CO2 emissions per hour of use of the Wirtgen W 150 CFi or alternative Cold Milling Machines.

    The carbon footprint evaluation can be carried out based on different fuel consumption scenarios or other variables.

    or visit the ERA Equipment CO2 Calculator to find out how to optimise your carbon footprint.

    service provided by ERA
