Technical specs - KL19.5 Kramer
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- operating weight
- 3.45 t
- Standard tyres
- 10.5-18
- Tipping load
- 1980 kg
- Wheel base
- 1.85 m
- Travel speed
- 20 km/h
- Steering mode
- A
- max. height at the shovel pivot point
- 3.05 m
- Overcharging height
- 2.89 m
- Max. discharge height
- 2.32 m
- Turning radius outside
- 2.7 m
- Transport length
- 4.95 m
- Transport width
- 1.59 m
- Transport height
- 2.39 m
- Engine manuf.
- Yanmar
- Engine type
- 4TNV88C
- Engine power
- 34 kW
- Displacement
- 2.19 l
- Revolutions at max torque
- 1950 rpm
- Max. torque
- 140 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 88x90 mm
- Emission level
- V
More technical details, like: weight, turning radius inside, model series, dimension lxwxh are available in the full technical specs.
Special equipment
- Cabin
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
Yes
- Quick hitch mech.
-
No
