Lectura specs Agricultural machinery Lawn and Garden Tractors Lawn and Garden Tractors Kubota Kubota GR1600-II specifications

Kubota GR1600-II Specifications & Technical Data (2020-2023)

Rate this machine now!

Engine power: 10kW – Weight: 365kg – Power source: Diesel – Cutting width: 1070mm – Transport length: 2.71m – Transport width: 1.115m

Technical specs - GR1600-II Kubota


Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Engine power 10 kW
  • Weight 365 kg
  • Power source Diesel
  • Cutting width 1070 mm
  • Transport length 2.71 m
  • Transport width 1.115 m
  • Transport height 1.615 m
  • Capacity 370 l
  • Travel speed 10 km/h
  • Back tyres 15x6.00-6
  • Front tyres 20x10-8
  • Transmission type HY
  • Model series GR
  • Engine manuf. Kubota
  • Engine type k.A.
  • Displacement 0.479 l
  • No. of cylinders 2
  • Emission level V

More technical details, like: average fuel consumption, fuel consumption range (min - max), turning radius, reverse travel speed, seat height , dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.
