Lectura specs Agricultural machinery Disc-zinc harrow Disc-zinc harrow Bugnot Bugnot Variodisk 230-32 specifications

Bugnot Variodisk 230-32 Specifications & Technical Data (2000-2012)

Rate this machine now!

Working width: 3.5m – Disc Ø: 660mm – Standard tyres: 15R22.5 – Transport width: 3m – Weight: 12t – Attachment: Z/ZD

Technical specs - Variodisk 230-32 Bugnot

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Working width 3.5 m
  • Disc Ø 660 mm
  • Standard tyres 15R22.5
  • Transport width 3 m
  • Weight 12 t
  • Attachment Z/ZD
  • No. of discs 32
  • Required power 73 kW

More technical details, like: no. of tines, no. of rows, stone protection are available in the full technical specs.

Special equipment

  • Feeler wheel
  • Pack Ring Roller
  • Cage Roller
  • Crackerboard
  • Hydraulic angle adjustment
