    SAME Explorer 80 LD Specifications & Technical Data (2020-2021)

    Rate this machine now!

    Engine power: 55.4kW – Back tyres: 420/70 R30 – Front tyres: 360/70 R20 – Transport length: 4.1m – Transport width: 2.341m – Transport height: 2.6m

    Technical specs - Explorer 80 LD SAME

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Engine power 55.4 kW
    Back tyres 420/70 R30
    Front tyres 360/70 R20
    Transport length 4.1 m
    Transport width 2.341 m
    Transport height 2.6 m
    Travel speed 40 km/h
    Transmission 20/20
    Transmission type LS
    Weight 3.6 t
    Control unit 2 ew/dw
    Steering h
    Engine manuf. SDF
    Engine type FARMotion
    Engine power 75 HP
    Displacement 2.887 l
    Revolutions at max torque 2200 rpm
    No. of cylinders 3
    Emission level Tier 4 f
    three point category ###
    Dimension lxwxh ###
    Max. torque ###
    Cylinder bore x stroke ###
    Weight ###

    is a 0 for the size specification so that means, that no information is available.

    Explorer 80 LD SAME - Special equipment

    • Cabin
    • Front hydraulics
    • Front PTO
    • Air brakes
    • ISO Bus
    • Aircondition
