    New Holland T7.230 Specifications & Technical Data (2015-2018)

    Rate this machine now!

    Manufactured by New Holland, this is the T 7.230 4wd tractor. Find and download detailed specs and data sheets for this machine he... Read more

    Manufactured by New Holland, this is the T 7.230 4wd tractor. Find and download detailed specs and data sheets for this machine here.

    This 4wd tractor is built to provide up to 147kW or 197 horse power, delivered from its powerful FPT engine to the 8.2t T 7.230 machine. The New Holland T 7.230 can be grouped in the biggest machine segment in the 4wd tractors category. The model's dimensions are 4.919m x 2.35m x 3.135m.

    The New Holland T 7.230 has been equipped and sold with Cabin, Air brakes and ISO Bus. It has been sold without air Front PTO and Front hydraulics as of 2017. There are more detailed specifications and machine descriptions available in the original New Holland T 7.230 specs data sheet.

    The production is still going in 2017, where this T 7.230 is available at a new list price between €153000 and €195000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

    The most commonly viewed New Holland models of this type on LECTURA Specs are the TD 4020 F, T 6.175 (400) and T 4.85, and 168 other 4wd tractors, which currently range from 35kW up to 410kW are also available. This T 7.230 4wd tractor, which has been in production between 2015 and 2017 ranks in the LECTURA index at #141. Throughout the production cycle of this T 7.230 4wd tractor, there have been around 168 models that average a price of €111900 for an age of 3 years Want more detailed specifications? Download the latest New Holland T 7.230 specs data sheet on LECTURA Specs today!

    Technical specs - T7.230 New Holland

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Engine power 147 kW
    • Back tyres 650/65 R42
    • Front tyres 540/65 R30
    • Transport length 4.919 m
    • Transport width 2.35 m
    • Transport height 3.135 m
    • Travel speed 50 km/h
    • Transmission type stfl.
    • Weight 8.2 t
    • Control unit -/3 ew/dw
    • Steering h
    • Engine manuf. FPT
    • Engine type NEF
    • Displacement 6.75 l
    • Revolutions at max torque 2300 rpm
    • Max. torque 940/1500 Nm
    • No. of cylinders 6
    • Emission level V
    • Model series ###
    • Transmission ###
    • three point category ###
    • Dimension lxwxh ###
    • Cylinder bore x stroke ###

    is a 0 for the size specification so that means, that no information is available.

    Special equipment

    • Cabin
    • Front hydraulics
    • Front PTO
    • Air brakes
    • ISO Bus
    • Aircondition
