New Holland T6.180 Specifications & Technical Data (2019-2020)

The New Holland T6.180 is a 4-wheel drive tractor manufactured from 2019 to 2020. It has a weight of 5.46 tons and is powered by a…

The New Holland T6.180 is a 4-wheel drive tractor manufactured from 2019 to 2020. It has a weight of 5.46 tons and is powered by an engine with a capacity of 116 kW. The tractor has a transport length of 4.51 meters and can travel at a speed of 40 km/h. It has a transport width of 2.34 meters and a transport height of 2.15 meters. The tractor is equipped with special equipment such as air brakes, air conditioning, and a cabin.

Technical specs - T6.180 New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
116 kW
Model series
T6
Back tyres
600/65 R38
Front tyres
480/65 R28
Transport length
4.51 m
Transport width
2.34 m
Transport height
2.15 m
Travel speed
40 km/h
Transmission
24/24
Transmission type
TLS
Weight
5.46 t
Control unit
-/3 ew/dw
Steering
h
Engine manuf.
FPT
Engine type
NEF
Displacement
6.75 l
Revolutions at max torque
1500 rpm
Max. torque
650 Nm
No. of cylinders
6
Cylinder bore x stroke
104x132 mm
Emission level
Tier 4b/ Stufe 4

More technical details, like: three point category, dimension lxwxh are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Front hydraulics
No
Front PTO
No
Air brakes
Yes
ISO Bus
No
Aircondition
Yes

Download datasheets (PDF)

FAQ

What is the weight of New Holland T6.180?

The weight of New Holland T6.180 is 5.46 tons.

What is the size of the New Holland T6.180 4WD tractor?

The size of the New Holland T6.180 4WD tractor is 2.34 meters in width, 2.15 meters in height, and 4.51 meters in length.

What engine does the New Holland T6.180 4WD tractor have?

The New Holland T6.180 4WD tractor has an FPT NEF engine with 158 kW power, 6.75 l displacement, 650 Nm max torque at 1500 rpm, and 6 cylinders.
