John Deere 9R 540 Specifications & Technical Data (2021-2025)

The John Deere 9R 540 is a 4-wheel drive tractor manufactured by John Deere since 2021. It has a weight of 18.8 tons and is powere…

The John Deere 9R 540 is a 4-wheel drive tractor manufactured by John Deere since 2021. It has a weight of 18.8 tons and is powered by an engine with a capacity of 437 kW. The tractor has a transport length of 7.593 meters and can travel at a speed of 40 km/h. It has a transport width of 3.05 meters and a transport height of 3.979 meters. The tractor is equipped with special equipment such as air conditioning, a cabin, and an ISO Bus.

9R 540

Years of manufacture: 2021—2025

Data sheet
Valuate & Sell
Spare parts
Transport
Events & News

Technical specs - 9R 540 John Deere

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power: 437 kW

Model series: 9R

Back tyres: 800/70 R38

Front tyres: 800/70 R38

Transport length: 7.593 m

Transport width: 3.05 m

Transport height: 3.979 m

Travel speed: 40 km/h

Transmission: 18/6

Transmission type: LS

Weight: 18.8 t

Control unit: -/4 ew/dw

Steering: h

three point category: 4H

Engine manuf.: John Deere

Engine type: PSS

Displacement: 13.6 l

Revolutions at max torque: 2100 rpm

Max. torque: 2492/1600 Nm

No. of cylinders: 6

Emission level: V

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin: Yes
Front hydraulics: No
Front PTO: No
Air brakes: No
ISO Bus: Yes
Aircondition: Yes

Download datasheets (PDF)

FAQ

What is the weight of John Deere 9R 540?

The weight of John Deere 9R 540 is 18.8 tons.

What is the size of the John Deere 9R 540 4WD tractor?

The size of the John Deere 9R 540 4WD tractor is 3.05 meters in width, 3.98 meters in height, and 7.59 meters in length.

How much is John Deere 9R 540 (2021 - 2024) worth?

The residual value of John Deere 9R 540 depends on machine's individual parameters. Visit LECTURA Valuation to check it.
