Claas Axion 940 Specifications & Technical Data (2018-2020)

Rate this machine now!

Manufactured by Claas, this is the Axion 940 4wd tractor. Find and download detailed specs and data sheets for this machine here. ... Read more

Manufactured by Claas, this is the Axion 940 4wd tractor. Find and download detailed specs and data sheets for this machine here.

The Claas Axion 940 is a 13.7t machine with Fiat engine which powers this model with up to 283kW or 379 horse power. The Axion 940 is categorised in the biggest machine segment in the 4wd tractors category. The Axion 940’s size is (no data) x 5.744m x 2.427m.

The Axion 940 is manufactured and distributed with Cabin, Air brakes and Aircondition. It does not include Front PTO and Front hydraulics. There are more detailed specifications and machine descriptions available in the original Claas Axion 940 specs data sheet.

The production is still going in 2017, where this Axion 940 is available at a new list price between €252000 and €321000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Claas currently produces 130 other 4wd tractors, which range from 55kW up to 390kW - the most visited on LECTURA Specs are Axion 930, Arion 550, Axion 950. Want more detailed specifications? Download the latest Claas Axion 940 specs data sheet on LECTURA Specs today!

Technical specs - Axion 940 Claas


Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Engine power 283 kW
  • Model series Axion
  • Back tyres 710/75R42
  • Front tyres 600/70 R34
  • Transport length 5.744 m
  • Transport height 2.427 m
  • Travel speed 50 km/h
  • Transmission 24/24
  • Transmission type stfl.
  • Weight 13.7 t
  • Control unit -/4 ew/dw
  • Steering h
  • three point category 3
  • Engine manuf. FPT
  • Engine type Cursor 9
  • Revolutions at max torque 1800 rpm
  • Max. torque 177 Nm
  • No. of cylinders 6
  • Emission level Tier 4 i

is a 0 for the size specification so that means, that no information is available.

Special equipment

  • Cabin
  • Front hydraulics
  • Front PTO
  • Air brakes
  • ISO Bus
  • Aircondition
