Claas Axion 920 Specifications & Technical Data (2018-2020)

Rate this machine now!

Manufactured by Claas, this is the Axion 920 4wd tractor. Find and download detailed specs and data sheets for this machine here. ... Read more

Manufactured by Claas, this is the Axion 920 4wd tractor. Find and download detailed specs and data sheets for this machine here.

This 4wd tractor is built to provide up to 239kW or 320 horse power, delivered from its powerful Fiat engine to the 13.4t Axion 920 machine. The Axion 920 is categorised in the biggest machine segment in the 4wd tractors category. The model's dimensions are 5.744m x (no data) x 2.427m.

Since 2018, this model has included ISO Bus, Air brakes and Aircondition. It does not include Front hydraulics and Front PTO. There are more detailed specifications and machine descriptions available in the original Claas Axion 920 specs data sheet.

The production is still going in 2017, where this Axion 920 is available at a new list price between €235000 and €299000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

At present, 130 other 4wd tractors, which range from 55kW up to 390kW are produced by Claas. Of these, Axion 950, Arion 550 and also Axion 930 are the most frequently visited on LECTURA Specs. Want more detailed specifications? Download the latest Claas Axion 920 specs data sheet on LECTURA Specs today!

Technical specs - Axion 920 Claas


Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Engine power 239 kW
  • Model series Axion
  • Back tyres 710/75R42
  • Front tyres 600/70 R34
  • Transport length 5.744 m
  • Transport height 2.427 m
  • Travel speed 50 km/h
  • Transmission 24/24
  • Transmission type stfl.
  • Weight 13.4 t
  • Control unit -/4 ew/dw
  • Steering h
  • three point category 3
  • Engine manuf. FPT
  • Engine type Cursor 9
  • Revolutions at max torque 1800 rpm
  • Max. torque 1600 Nm
  • No. of cylinders 6
  • Emission level Tier 4 i

is a 0 for the size specification so that means, that no information is available.

Special equipment

  • Cabin
  • Front hydraulics
  • Front PTO
  • Air brakes
  • ISO Bus
  • Aircondition
