Claas Arion 630 Specifications & Technical Data (2018-2020)

Rate this machine now!

Claas is the manufacturer of the 4wd tractor model Arion 630. Find and download detailed specs and data sheets for this machine he... Read more

Claas is the manufacturer of the 4wd tractor model Arion 630. Find and download detailed specs and data sheets for this machine here.

Equipped with a powerful John Deere engine, this Arion 630 6.58t machine can provide 121kW or 162 horse power for the 4wd tractor. The Arion 630 is categorised in the biggest machine segment in the 4wd tractors category. The Arion 630’s size is (no data) x 5.16m x 3.01m.

Since 2018, this model has included Cabin and Aircondition. Front hydraulics, Air brakes and Front PTO are not provided on this model as of 2017. There are more detailed specifications and machine descriptions available in the original Claas Arion 630 specs data sheet.

This model can be acquired for a list price between €120000 and €153000. Production of the Arion 630 continues in 2017. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Claas currently produces 130 other 4wd tractors, which range from 55kW up to 390kW - the most visited on LECTURA Specs are Axion 930, Arion 550, Axion 950. Want more detailed specifications? Download the latest Claas Arion 630 specs data sheet on LECTURA Specs today!

Technical specs - Arion 630 Claas


Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Engine power 121 kW
  • Model series Arion
  • Back tyres 580/70 R38
  • Front tyres 480/70 R28
  • Transport length 5.16 m
  • Transport height 3.01 m
  • Travel speed 40 km/h
  • Transmission 24/24
  • Transmission type LS
  • Weight 6.58 t
  • Control unit -/3 ew/dw
  • Steering h
  • three point category 3
  • Engine manuf. John Deere
  • Engine type D.P.S. PSS
  • Displacement 6.788 l
  • Revolutions at max torque 2000 rpm
  • Max. torque 703 Nm
  • No. of cylinders 6
  • Emission level Tier 4

is a 0 for the size specification so that means, that no information is available.

Special equipment

  • Cabin
  • Front hydraulics
  • Front PTO
  • Air brakes
  • ISO Bus
  • Aircondition
