Claas Arion 610 Specifications & Technical Data (2018-2020)
Claas is the manufacturer of the 4wd tractor model Arion 610. Find and download detailed specs and data sheets for this machine he... Read more
Claas is the manufacturer of the 4wd tractor model Arion 610. Find and download detailed specs and data sheets for this machine here.
Equipped with a powerful John Deere engine, this Arion 610 6.58t machine can provide 107kW or 143 horse power for the 4wd tractor. The Arion 610 is categorised in the biggest machine segment in the 4wd tractors category. The Arion 610’s size is (no data) x 5.16m x 3.01m.
The Claas Arion 610 has been equipped and sold with Cabin and Aircondition. Front hydraulics, Air brakes and ISO Bus are not provided on this model as of 2017. There are more detailed specifications and machine descriptions available in the original Claas Arion 610 specs data sheet.
This model can be acquired for a list price between €111000 and €141000. Production of the Arion 610 continues in 2017. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.
Claas currently produces 130 other 4wd tractors, which range from 55kW up to 390kW - the most visited on LECTURA Specs are Arion 550, Axion 950, Axion 930. Want more detailed specifications? Download the latest Claas Arion 610 specs data sheet on LECTURA Specs today!
Technical specs - Arion 610 Claas
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.
- Engine power 107 kW
- Model series Arion
- Back tyres 580/70 R38
- Front tyres 480/70 R28
- Transport length 5.16 m
- Transport height 3.01 m
- Travel speed 40 km/h
- Transmission 24/24
- Transmission type LS
- Weight 6.58 t
- Control unit -/3 ew/dw
- Steering h
- three point category 3
- Engine manuf. John Deere
- Engine type D.P.S. PSS
- Displacement 6.788 l
- Revolutions at max torque 2000 rpm
- Max. torque 640 Nm
- No. of cylinders 6
- Emission level Tier 4
is a 0 for the size specification so that means, that no information is available.
- Front hydraulics
- Front PTO
- Air brakes
- ISO Bus
Carbon footprint calculator for 4WD Tractors
See the ERA equipment CO2 Calculator to find out the CO2 emissions per hour of use of the Claas Arion 610 or alternative 4WD Tractors.
The carbon emission evaluation can be carried out based on different biofuel scenarios or other variables.
or visit the ERA Equipment CO2 Calculator to find out how to optimise your carbon footprint.
Download datasheets (PDF)
- Arion 610 Claas Specification for Europe (DE)
- Arion 610 Claas Specification for Europe (EN)
- Arion 610 Claas Specification for Europe (ES)
- Arion 610 Claas Specification for Europe (FR)
- Arion 610 Claas Specification for Europe (IT)
- Arion 610 Claas Specification for Europe (NL)
- Arion 610 Claas Specification for Europe (PL)
