Claas Arion 530 Specifications & Technical Data (2018-2020)

Rate this machine now!

The Arion 530 CMatic 4wd tractor model is manufactured by Claas. Find and download detailed specs and data sheets for this machine... Read more

The Arion 530 CMatic 4wd tractor model is manufactured by Claas. Find and download detailed specs and data sheets for this machine here.

The Claas Arion 530 CMatic is a 5.47t machine with John Deere engine which powers this model with up to 107kW or 143 horse power. This Claas 4wd tractor belongs to the biggest machine segment in the 4wd tractors category. The Arion 530 CMatic’s size is (no data) x 4.89m x 2.96m.

The Arion 530 CMatic is manufactured and distributed with Aircondition, Cabin and Air brakes. It does not include Front PTO, ISO Bus and Front hydraulics. There are more detailed specifications and machine descriptions available in the original Claas Arion 530 CMatic specs data sheet.

This model can be acquired for a list price between €111000 and €141000. Production of the Arion 530 CMatic continues in 2017. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Claas currently produces 130 other 4wd tractors, which range from 55kW up to 390kW - the most visited on LECTURA Specs are Arion 550, Axion 950, Axion 930. Want more detailed specifications? Download the latest Claas Arion 530 CMatic specs data sheet on LECTURA Specs today!

Technical specs - Arion 530 Claas


Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Engine power 107 kW
  • Model series Arion
  • Back tyres 18.4 R38
  • Front tyres 14.9 R28
  • Transport length 4.89 m
  • Transport height 2.96 m
  • Travel speed 50 km/h
  • Transmission type stfl.
  • Weight 5.47 t
  • Control unit -/3 ew/dw
  • Steering h
  • three point category 3
  • Engine manuf. John Deere
  • Engine type D.P.S. PSS
  • Displacement 4.525 l
  • Revolutions at max torque 2000 rpm
  • Max. torque 612 Nm
  • No. of cylinders 4
  • Emission level Tier 4

is a 0 for the size specification so that means, that no information is available.

Special equipment

  • Cabin
  • Front hydraulics
  • Front PTO
  • Air brakes
  • ISO Bus
  • Aircondition
