    Carraro TRH 9400 Specifications & Technical Data (2005-2011)

    Rate this machine now!

    The TRH 9400 4wd tractor model is manufactured by Carraro. Find and download detailed specs and data sheets for this machine here.... Read more

    The TRH 9400 4wd tractor model is manufactured by Carraro. Find and download detailed specs and data sheets for this machine here.

    Equipped with a powerful VM engine, this TRH 9400 2.19t machine can provide 62.4kW or 83 horse power for the 4wd tractor. The Carraro TRH 9400 can be grouped in the medium sized machine segment in the 4wd tractors category. The model's dimensions are 3.28m x 1.27m x 2.12m.

    Since 2005, this model has included Aircondition and Cabin. It does not include Air brakes, ISO Bus and Front hydraulics. There are more detailed specifications and machine descriptions available in the original Carraro TRH 9400 specs data sheet. Download a free data sheet in German from LECTURA Specs.

    This model can be acquired for a list price between €40000 and €51000. Production of the TRH 9400 stopped in 2011. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

    The most commonly viewed Carraro models of this type on LECTURA Specs are the SRX 8400, TGF 9400 S and TN 5800 major, and 31 other 4wd tractors, which currently range from 35kW up to 73kW are also available. Want more detailed specifications? Download the latest Carraro TRH 9400 specs data sheet on LECTURA Specs today!

    Technical specs - TRH 9400 Carraro

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Engine power 62.4 kW
    • Back tyres 250/80-18
    • Front tyres 250/80-18
    • Transport length 3.28 m
    • Transport width 1.27 m
    • Transport height 2.12 m
    • Travel speed 40 km/h
    • Transmission type stfl.
    • Weight 2.19 t
    • Control unit 1/2 ew/dw
    • Engine manuf. VM
    • Engine type k.A.
    • Emission level Tier 2

    More technical details, like: model series, transmission, steering, three point category, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

    is a 0 for the size specification so that means, that no information is available.

    Special equipment

    • Cabin
    • Front hydraulics
    • Front PTO
    • Air brakes
    • ISO Bus
    • Aircondition
