    Lectura specs Agricultural machinery 4WD Forage Harvesters 4WD Forage Harvesters John Deere John Deere 9600 specifications

    John Deere 9600 Specifications & Technical Data (2018-2021)

    Rate this machine now!

    Engine power: 460kW – Back tyres: 620/70 R30 – Front tyres: 900/60 R42 – Min. Pick-up width: 3.63m – Max. pick-up width: 4m – Transmission type: A

    Technical specs - 9600 John Deere

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Engine power 460 kW
    Back tyres 620/70 R30
    Front tyres 900/60 R42
    Min. Pick-up width 3.63 m
    Max. pick-up width 4 m
    Transmission type A
    Steering HH
    Brakes S
    Travel speed 40 km/h
    Transport length 6 m
    Transport width 3 m
    Transport height 3 m
    Engine manuf. John Deere
    Engine type 6135HZ021
    Engine power 617 HP
    Displacement 13,5 l
    No. of cylinders 6
    Emission level Tier 4 f/EU V
    Weight ###
    Dimension lxwxh ###
    Revolutions at max torque ###
    Max. torque ###
    Cylinder bore x stroke ###
    Weight ###

    Basic model, Self-propelled is a 0 for the size specification so that means, that no information is available.

    9600 John Deere - Special equipment

    • Cabin
    • Air brakes
    • All-wheel drive
    • Overload safety
    • Metal detector
    • Rollover protection
    • Aircondition

    Download data sheets - John Deere 9600
