Case IH Farmall 75 C Specifications & Technical Data (2021-2024)

Rate this machine now!

The Case IH Farmall 75 C is a 2 Wheel-Drive Tractor manufactured since 2021, weighing 2.88 tons and powered by a 55 kW engine. It ... Read more

The Case IH Farmall 75 C is a 2 Wheel-Drive Tractor manufactured since 2021, weighing 2.88 tons and powered by a 55 kW engine. It has a travel speed of 40 km/h and a transport length of 4.001 m, width of 1.922 m and height of 2.495 m. It is equipped with a Cabin.

Technical specs - Farmall 75 C Case IH


Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Engine power 55 kW
  • Model series Farmall
  • Back tyres 16.9 R30
  • Front tyres 14.9L R20
  • Transport length 4.001 m
  • Transport width 1.922 m
  • Transport height 2.495 m
  • Travel speed 40 km/h
  • Transmission 12/12
  • Transmission type m
  • Weight 2.88 t
  • Control unit -/2 ew/dw
  • Steering h
  • Engine manuf. FPT
  • Engine type k.A.
  • Displacement 3.4 l
  • Revolutions at max torque 2200 rpm
  • Max. torque 375/1400 Nm
  • No. of cylinders 4
  • Emission level V

More technical details, like: fuel consumption range (min - max), three point category, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

  • Cabin
  • Front hydraulics
  • Front PTO
  • Air brakes
  • ISO Bus
  • Aircondition
