Krone BiG X 580 Specifications & Technical Data (2020-2024)

Rate this machine now!

Engine power: 436kW – Model series: BIG X – Back tyres: 540/65 R 30 – Front tyres: 800/65 R 32 – Min. Pick-up width: 3m – Max. pick-up width: 3m

Technical specs - BiG X 580 Krone

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Engine power 436 kW
  • Model series BIG X
  • Back tyres 540/65 R 30
  • Front tyres 800/65 R 32
  • Min. Pick-up width 3 m
  • Max. pick-up width 3 m
  • Weight 14.1 t
  • Travel speed 40 km/h
  • Transport length 7.52 m
  • Transport width 3 m
  • Transport height 3.91 m
  • Engine manuf. MTU
  • Engine type 6R1500
  • Displacement 15.6 l
  • No. of cylinders 6
  • Emission level V

More technical details, like: transmission type, steering, brakes, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model, Self-propelled is a 0 for the size specification so that means, that no information is available.

Special equipment

  • Cabin
  • Air brakes
  • All-wheel drive
  • Overload safety
  • Metal detector
  • Rollover protection
  • Aircondition
