    Krone BiG X 530 Specifications & Technical Data (2020-2023)

    Rate this machine now!

    Engine power: 390kW – Back tyres: 540/65 R 30 – Front tyres: 800/65 R 32 – Min. Pick-up width: 3m – Max. pick-up width: 3m – Weight: 13.9t

    Technical specs - BiG X 530 Krone


    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Engine power 390 kW
    • Back tyres 540/65 R 30
    • Front tyres 800/65 R 32
    • Min. Pick-up width 3 m
    • Max. pick-up width 3 m
    • Weight 13.9 t
    • Travel speed 40 km/h
    • Transport length 7.52 m
    • Transport width 3 m
    • Transport height 3.9 m
    • Engine manuf. MTU
    • Engine type 6R1300
    • Displacement 12.8 l

    More technical details, like: model series, transmission type, steering, brakes, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

    Basic model, Self-propelled is a 0 for the size specification so that means, that no information is available.

    Special equipment

    • Cabin
    • Air brakes
    • All-wheel drive
    • Overload safety
    • Metal detector
    • Rollover protection
    • Aircondition
