    Snorkel A38E Specifications & Technical Data (2010-2023)

    7,00/10 Rate this machine now!

    The A38E articulated telescopic work platform model is manufactured by Snorkel. Find and download detailed specs and data sheets f... Read more

    The A38E articulated telescopic work platform model is manufactured by Snorkel. Find and download detailed specs and data sheets for this machine here.

    The A38E is categorised in the smallest machine segment in the articulated telescopic work platforms category. The model's dimensions are 4.1m x 1.5m x 2m. The Articulated Telescopic Work Platform A38E Snorkel is designed to travel at a top speed of 4km/h. The maximum net load of this 3.8kg model is 215kg. It is able to operate in up to 13.5m working height. Max. Horizontal reach of this A38E model from Snorkel is 6,1m. 2 persons are allowed to stand on the platform at the same time thanks to 1.24m of platform length and 0.71m of platform width.

    Rigid cage boom, All-wheel steering and Articulated cage boom are not provided on this model as of 2018. Get the original Snorkel A38E datasheet for even more detailed specifications and machine details. Available in Spanish, French, German and English, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

    This model can be acquired for a list price between €33,000 and €42,000. Production of the A38E continues in 2018. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system. The most recent model of this machine is priced between €33,000 and €42,000. Moreover this model is still being manufactured today.

    Based on other articulated telescopic work platforms specifications and pricing variations, the Snorkel A38E can be considered similar to the AIRO A 13 JE, AIRO A 13 JED and Basket 14 AJ Electron. Snorkel currently produces 9 other articulated telescopic work platforms, which range from 8.1m up to 27.7m - the most visited on LECTURA Specs are A46JE, A46JRT, A46JRT. Having been in production from 2010 to 2018, the A38E articulated telescopic work platform ranks in the LECTURA index at #17. Want more detailed specifications? Download the latest Snorkel A38E specs data sheet on LECTURA Specs today!

    Technical specs - A38E Snorkel


    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Working height 13.5 m
    • Platform length 1.11 m
    • Platform width 0.69 m
    • Transport length 4.1 m
    • Transport width 1.5 m
    • Transport height 2 m
    • Weight 3880 kg
    • Net load 215 kg
    • Max. Reach horizontal 6.1 m
    • Persons 2
    • max. climbing ability 36 %
    • Travel speed 4 km/h
    • Turning radius outside 2.4 m
    • Power source E
    • Rotation 360 °

    More technical details, like: brace support length, brace support width, proportional control, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

    IPAF: 3b

    Special equipment

    • Rigid cage boom
    • Articulated cage boom
    • All-wheel steering
