Snorkel S2770RTE
- Working height:
- 10.1 m
- Platform length:
- 2.8 m
- Platform width:
- 1.6 m
- Transport length:
- 3.4 m
Snorkel S2770RTE Wheeled scissor lifts (2020 - 2025) Specifications & Dimensions
Technical specs - S2770RTE Snorkel
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Working height
- 10.1 m
- Platform length
- 2.8 m
- Platform width
- 1.6 m
- Transport length
- 3.4 m
- Transport width
- 1.8 m
- Transport height
- 2.61 m
- Weight
- 2886 kg
- Net load
- 580 kg
- Travel speed
- 4.5 km/h
- Turning radius outside
- 5 m
- Proportional control
- j
- max. climbing ability
- 35 %
- Platform extension
- 1.2 m
- Power source
- E
- Engine manuf.
- Kohler
- Engine type
- KDI2504
- Engine power
- 48 kW
- Max. torque
- 305/1500 Nm
- No. of cylinders
- 4
More technical details, like: brace support length, brace support width, persons, model series, dimension lxwxh, displacement, revolutions at max torque, cylinder bore x stroke, emission level are available in the full technical specs.
IPAF: 3a
Special equipment
- All-wheel steering
-
No
- Foldable handrail
-
Yes
