Rothlehner RX 780 Wheeled scissor lifts (1997 - 2009) Specifications & Dimensions

Name: Rothlehner RX 780 Wheeled scissor lifts
Brand: Rothlehner

Rothlehner is the manufacturer of the wheeled scissor lift model RX 780. Find and download detailed specs and data sheets for this…

Rothlehner is the manufacturer of the wheeled scissor lift model RX 780. Find and download detailed specs and data sheets for this machine here.

The RX 780 is categorised in the smallest machine segment in the wheeled scissor lifts category. This 1365kg model can operate with 227kg of net load. This Wheeled Scissor Lift from Rothlehner can provide a working height of 7.8m. The 2.46m by 0.72m platform of this model is designed for 2 persons.

It has been sold without Foldable handrail and All-wheel steering as of 2009. Find detailed specifications and machine details in the original Rothlehner RX 780 datasheet.

This model can be acquired for a list price between €15,000 and €18,000. Production of the RX 780 stopped in 2009. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Based on other wheeled scissor lifts specifications and pricing variations, the Rothlehner RX 780 can be considered similar to the JLG 1932 e 2, Skyjack SJ III 3219 and MEC 1932 ES. At present, other wheeled scissor lifts, which range from up to are produced by Rothlehner. Of these, are the most frequently visited on LECTURA Specs. Want more detailed specifications? Download the latest Rothlehner RX 780 specs data sheet on LECTURA Specs today!

RX 780

Years of manufacture: 1997—2009

Buy & Rent
Spare parts
Transport
Events & News

Technical specs - RX 780 Rothlehner

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Working height: 7.8 m

Platform length: 2.46 m

Platform width: 0.72 m

Weight: 1365 kg

Net load: 227 kg

Persons: 2

Platform extension: 0.9 m

Model series: RX

More technical details, like: brace support length, brace support width, transport length, transport width, transport height, travel speed, turning radius outside, proportional control, max. climbing ability, power source, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

IPAF: 3a

Special equipment

All-wheel steering: No
Foldable handrail: No
