JCB S1930E Wheeled scissor lifts (2017 - 2023) Specifications
Working height: 7.71m – Platform length: 1.64m – Platform width: 0.76m – Transport length: 1.78m – Transport width: 0.77m – Transp... Read more
Working height: 7.71m – Platform length: 1.64m – Platform width: 0.76m – Transport length: 1.78m – Transport width: 0.77m – Transport height: 1.85m
Find manuals and specs of JCB S1930E Wheeled scissor lifts (2017 - 2023). Find all available technical data like work height, platform length and width below:
Technical specs - S1930E JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.
- Working height 7.71 m
- Platform length 1.64 m
- Platform width 0.76 m
- Transport length 1.78 m
- Transport width 0.77 m
- Transport height 1.85 m
- Weight 1696 kg
- Net load 230 kg
- Persons 2
- Travel speed 3 km/h
- Turning radius outside 1.49 m
- Proportional control j
- max. climbing ability 25 %
- Platform extension 0.9 m
- Power source E
- Model series Scherenb
- Engine manuf. Kohler
- Engine type KDI 2504
- Engine power 48 kW
- Max. torque 305/1500 Nm
- No. of cylinders 4
More technical details, like: average fuel consumption, fuel consumption range (min - max), brace support length, brace support width, dimension lxwxh, displacement, revolutions at max torque, cylinder bore x stroke, emission level are available in the full technical specs.
IPAF: 3a
Special equipment
- All-wheel steering
- Foldable handrail
