A crane is a device that can be used for vertical lifting and lowering of large loads. In addition to the possible vertical movements, the loads can also be moved horizontally in different directions with a crane. The combination of vertical and horizontal movements and their high lifting capacity makes cranes ideal for loading goods.
Technical specs - LEO15GT plus TEUPEN
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.
- Working height 15.4 m
- Platform length 1.4 m
- Platform width 0.7 m
- Brace support length 3.31 m
- Brace support width 3.03 m
- Transport length 5.2 m
- Transport width 0.78 m
- Transport height 1.99 m
- Weight 2200 kg
- Net load 200 kg
- Max. Reach horizontal 7,9 m
- Persons 2
- max. climbing ability 36 %
- Proportional control e/h/j
- Travel speed 1,5 km/h
- Track width 200 mm
More technical details, like: power source, rotation, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
IPAF: 3b
Special equipment
- Rigid cage boom
- Articulated cage boom
